Bianchi E- Omnia 2026

Technical specifications
Size and Frame Geometry
Motor Unit
Motor

OLI Edge, 90Nm, 250W

Battery

Internal battery 630Wh

Display

Display High Vision

Frameset
Frame

E-OMNIA C-Type chain drive ALU sizes: 45-50-55 – 9×135 mm quick release dropouts – Post mount 180 disc brake type – Internal cable routing in DT – 625Wh compatible – custom rear carrier integrated in the frame design

Fork

Suntour XCM34-Boost NLO DS 29″, 120mm travel, 1.5″ tapered HT, w/ 15AH2-110 TA, minimum 160mm rotor, maximum 203mm rotor, 34mm stanchions, Coil w/ preload adjuster

Headset

FSA NO.55R/558 1.5″

Drivetrain
Crankset

FSA CK-320/IS Die cast AL crank 170mm ISIS

Shifter

Shimano, SL-M4100-R, DEORE, 10-SPEED

Rear Derailleur

Shimano, RD-M4120, DEORE, SGS 10/11-SPEED

Bottom Bracket

Included in the motor

Chain

KMC e10S NPBK Anti-Rust

Brakes
Brakes

Promax DSK-925, Mineral Oil

Rotor

Promax DSK-925, 180mm

Cockpit
Stem

Velomann, diam. 31,8, size: 90mm for SM, 110mm for
LG, MD

Handlebar

Velomann, 31.8*630 / Rise 34mm / Back Sweep 41°

Grip

Hermans Grip 130

Wheels
Wheels

Velomann E-Sport Tubeless Ready 29″, 25-622, 32 hole black

Tire

Vittoria e-Randonneur, 50-622

Front Hub

Formula CL-811 for Center Lock, 32h, 15x110mm TA, 2SB

Front Hub

Formula CL-1422 Center lock, 32hole, 14G, O.L.D. 135mm AXEL145mm, for Shimano 8/9/10speed with Quick release

Saddle
Seatpost

Velomann 31.6*350, suspension seatpost

Saddle

Velomann, steel rail, 254x183mm, 420gr.

Accessories
Pedals

VPE-889P, PP body, reflector included

Rear Carrier

custom rear carrier integrated into the frame design

Mudguard

SKS PET Mudguards A65 R /28

Rear Light

Spanninga custom integrated light

Kickstand

Velomann load 35kg

Front Light

Spanninga custom integrated light, 40 lux

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
color
4G – CK16 / Dark Celeste, 4H – Metal Brown / Graphite, 4I – Metal Grey / Graphite
